Optical Headend Transmitter 1 wavelength (1550 nm). The 4001 Optical Compact Headend converts 1 input to 1550nm optical wavelength. Use in combination with Ref. 4000 to use 3 wavelengths in your fiber distribution system.
Product code: 4001
Optical Headend Transmitter 1 wavelength (1550 nm)
The 4001 Optical Compact Headend converts 1 input to 1550nm optical wavelength.
Use in combination with Ref. 4000 to use 3 wavelengths in your fiber distribution system.
• 1 Wideband input
• frequency range: 5-2400 MHz
• 1 Optical output (wavelength 1550nm)
• 9 dBm output power
• optical input for loopthrough (from ref. 4000)
| Outputs | 1 Optical |
| Inputs | 1 RF + 1 optical (loopthrough from ref. 4000) |
| Optical wavelength | 1550nm |
| Frequency range | 5 – 2400MHz |
| Optical output power | 9dBm (per wavelength) |
| Ripple | +/- 2.5dBm |
| Optimal input level | SAT: 80dBµV per transponder TERR: 70dBµV per MUX |
| Input attenuator | 0 – 15dB |
| Laser type | DFB |
| Laser LED control | Green LED on |
| LNB power supply | 12.8V / max. 240 mA |
| Optical connectors | SC/APC |
| RF connectors | F-female |
| Power consumption | 6.0W |
| Power supply | 200 – 240VAC |
| Operating temperature range | -20°C to +55°C |
| Protection class | IP 50 |
| Dimensions | 225 x 190 x 86mm |
| Weight | 1.8kg |
